• Low wind resistance, large filtering area and high dust holding capacity;
• Rugged aluminum alloy frame, resistant to high temperature, no rust and no deformation;
• With long service life；
Advantages:
• Rugged aluminum alloy frame, resistant to high temperature, no rust and no deformation;
• Low wind resistance, large filtering area and high dust holding capacity;
• Thin thickness and light weight;
• With long service life；
• Using glass fiber/PTFE filter material, double-sided filter screen protection;
• Using low-resistance and high-efficiency filter paper to capture dust particles of 0.3μm-1μm;
• With filtration efficiency of 99.995% - 99.99995% @0.3μm;
Specifications:
|
Application |
Particulate and molecular filters |
|
Outer Frame |
Aluminum alloy |
|
Dimension |
Filter section size |
|
Filter Material |
Glassfiber /PTFE |
|
Partition |
Hot-melt adhesive |
|
Sealant |
Two-component polyurethane adhesive |
|
Protective net |
Corrosion resistant spray-paint net |
|
Filtration efficiency |
99.995%-99.999995%@0.3μm |
Relationship Between Resistance with Air Volume
305 x 305 x 35
Glass fiber filter paper
Galvanized steel
Medium density board
Aluminum alloy plate
Stainless steel plate
Type
Dimension(mm)
Rated Air Volume(m3/h)
Initial Resistance(Pa)
Efficiency(%)
Material
Filter Element
Outer Frame
ZNG-1
110
<200
>99.99
ZNG-2
305 x 305 x 69
250
ZNG-4
610 x 610 x 35
450
ZNG-7
610 x 610 x 50
700
ZNG-10
610 x 610 x 69
1000
ZNG-11
915 x 610 x 50
1100
ZNG-13
610 x 610 x 80
1300
ZNG-15
915 x 610 x 69
1500
ZNG-19
915 x 610 x 80
1900
ZNG-20
1220 x 610 x 69
2000
*Note: Non-standard air filter products of different specifications can be customized according to customer requirements.
